HPG-2003-1: The Winchester

  • Regular price $0.00 $0.00 On Sale

    Click the "Add to Cart" button to review your order.

    You're making a very smart decision to choose a House Plan Gallery plan!


    Bedrooms: 3 / Baths: 2.5

    Living Sq. Ft.: 2003

    Width: 65' - 0" / Depth: 56' - 8"

    Architectural style(s):
    Cottage /

    Country / New England / Ranch / Traditional

    This design includes many of the most popular features normally found in larger homes. Isolated master suite with oversized jet tub, separate shower, large his and her walk-in closets, dual lavatories, and spacious vanity. Large laundry room with plenty of space for storing/folding clothing and other goods. Expansive great room features easy-access to the kitchen and includes the much-requested gas log fireplace and vaulted ceiling. The "flex space" is very useful addition to serve as that much-needed home office or other family space. Kitchen includes raised bar for friends and family to visit. Enjoy a relaxing evening on your front covered porch or screened porch. The rear patio provides an excellent space for grilling-out and spending time with friends and family. A great home that will fit your family's needs for years to come!

    Foundation Type(s) Available:
    Basement / Crawlspace / Slab

    Levels: 1    Garage: Yes       Wall type: 2x4
    Exterior finish: Brick / Siding  Bonus Room:  No

    =======

    Designer Comments:
    First Floor: 2003 sq. ft. (living)
    Front Porch: 107 sq. ft. (unheated)
    Rear Porch: 118 sq. ft. (unheated)
    Garage: 493 sq. ft. (unheated)

    No video currently available.

    All of our house plans include the following:

    Cover Sheet Showing architectural rendering of residence

    Floor Plan(s) In general, each house plan set includes floor plans at 1/4" scale with a door and window schedule. Floor plans are typically drawn with 4" exterior walls. However, some plans may have details/sections for both 2"x4" and 2"x6" wall framing. Please see "Exterior Wall Framing" specification above for availability.

    Foundation Plan and Details Electrical Plan with electrical symbols legend: In general, each house plan set includes an electrical plan which will show the locations of lights, receptacles, switches, etc.

    Roof Drainage Plan In general each house plan set may include a roof drainage plan which will show the layouts of all roof sections/planes.

    Exterior Elevations In general, each house plan set includes all applicable front, sides and rear elevations, as well as any special exterior details.

    Interior Elevations Where applicable, each house plan set includes relevant interior elevations, including cabinets, cabinet details, columns and walls with unique conditions.

    Single Use License Unless you buy a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold or transferred.

    We can modify this house plan to fit your EXACT needs!

    To get started, we can provide you with a 100% FREE No-Obligation modifications quote.

    Just click on the link below to fill out our quick & easy online form and let us know exactly what modifications you'd like done, and we'll email over your free quote within 1-2 business days!

    Get started by CLICKING HERE

    Customer Reviews

    Based on 3 reviews Write a review

    You'll Receive Your House Plans FAST!  Order a PDF or CAD file today, and we will email your house plans today!

    Order a printed plan package (1 Set, 5 Set, or Reproducible), and we'll print and ship your plans today as well (typically 3-5 days to receive via UPS)!

    Upgrade to expedited shipping for even faster delivery to your front door!
